Matrice 300 RTK

• Unfolded Dimensions (excluding propellers): 810×670×430 mm (L×W×H)
• Folded Dimensions (including propellers): 430×420×430 mm (L×W×H)
• Weight: Approx. 3.6 kg (without batteries), 6.3 kg (with two TB60 batteries)
• Max Takeoff Weight: 9 kg
• Diagonal Wheelbase: 895 mm
• Max Flight Time: 55 minutes
• Max Speed: 23 m/s (S mode), 17 m/s (P mode)
• Max Ascent Speed: 6 m/s (S mode), 5 m/s (P mode)
• Max Descent Speed: 5 m/s (vertical, S mode), 4 m/s (vertical, P mode), 7 m/s (tilt)
• Hovering Accuracy (RTK): ±0.1 m (vertical), ±0.1 m (horizontal)
• Operating Frequency: 2.4000-2.4835 GHz, 5.725-5.850 GHz
• Remote Controller Transmission Range: Up to 15 km (NCC/FCC), 8 km (CE/MIC/SRRC)
• Ingress Protection Rating: IP45
• Supported GNSS Systems: GPS + GLONASS + BeiDou + Galileo
• Operating Temperature Range: -20°C to 50°C (-4°F to 122°F)
• Obstacle Sensing Range: 0.7–40 m (horizontal), 0.6–30 m (vertical)
• FPV Camera Resolution: 960p, 145° FOV, 30 fps
• Vision System Operating Environment: Surfaces with clear patterns, >15 lux lighting
• Intelligent Flight Battery (TB60): 5935 mAh, 52.8 V, LiPo 12S, 274 Wh, self-heating
• BS60 Battery Station Capacity: Charges 8 * TB60 and 4 * WB37 batteries
• BS60 Battery Station Power: Max 1070W input, 992W output (220–240V), 750W (100–120V)

DJI Matrice 300 RTK – The Drone That Works Harder Than You Ever Will

The DJI Matrice 300 RTK is a flagship enterprise drone engineered for demanding industrial and commercial operations. Built on DJI’s advanced flight platform, it delivers exceptional reliability, extended flight time, and superior intelligence, making it the preferred choice for professionals in infrastructure inspection, public safety, surveying, mapping, and emergency response.

Unmatched Performance & Endurance With a maximum flight time of 55 minutes, the Matrice 300 RTK significantly outperforms most enterprise drones in its class. It supports a maximum takeoff weight of 9 kg and can carry a wide range of payloads up to 930g on a single downward gimbal. The drone features TB60 Intelligent Flight Batteries with self-heating technology, enabling reliable operation in extreme temperatures ranging from -20°C to 50°C.

Precision RTK Positioning Equipped with RTK (Real-Time Kinematic) technology, the Matrice 300 RTK achieves centimeter-level accuracy: 1 cm + 1 ppm (horizontal) and 1.5 cm + 1 ppm (vertical). This makes it perfect for high-precision mapping, 3D modeling, and geospatial data collection. The advanced Vision System and Infrared ToF Sensing provide omnidirectional obstacle avoidance, while the IP45 ingress protection rating ensures the drone can withstand dust and water jets — ideal for harsh outdoor environments.

Versatile Payload & Gimbal Options The Matrice 300 RTK supports multiple gimbal configurations including single downward, dual downward, upward, and triple gimbal setups. It is fully compatible with industry-leading cameras such as:

• Zenmuse H20 / H20T (Hybrid thermal & zoom)
• Zenmuse XT2 / XT S (Thermal)
• Zenmuse P1 (Full-frame photogrammetry)
• Zenmuse L1 (LiDAR + RGB)

This flexibility allows users to tackle diverse missions from thermal inspections of power lines and solar farms to detailed aerial surveying and search & rescue operations.

Robust Transmission & Control OcuSync Enterprise transmission delivers a maximum control range of 15 km (FCC) with crystal-clear 960p FPV feed. The smart remote controller features a built-in 5.5-inch high-brightness screen and supports up to 4.5 hours of operation with the external WB37 battery.

Built for Enterprise Reliability The Matrice 300 RTK includes advanced safety features such as redundant IMU & barometer systems, six-directional sensing, and intelligent flight modes. The BS60 Intelligent Battery Station can charge up to 8 TB60 batteries and 4 WB37 batteries efficiently, making it perfect for large-scale operations.

Whether you are conducting critical infrastructure inspections, creating accurate topographic maps, or supporting emergency services, the DJI Matrice 300 RTK sets a new standard in enterprise drone technology. Its combination of endurance, precision, weather resistance, and payload versatility makes it a future-proof investment for serious drone professionals.

Available at DJI Drone Store India  Your trusted source for authentic DJI Enterprise solutions.
