DJI AL1 Spotlight

Product Name: DJI AL1 Spotlight
Weight: 91 g
Power: 32 W
Illuminance: 4.3 lux @ 100 m
Illumination Angle: 23°
Illumination Area: Up to 2,200 m²
Modes: Always-on, Strobe
Tilt Control Range: -90° to 35°
Max Tilt Speed: 120°/s
Protection: IP55

DJI AL1 Spotlight
The DJI AL1 Spotlight is a high-performance, lightweight aerial illumination accessory designed specifically for the DJI Matrice 4D Series enterprise drones. Weighing just 91g (excluding bracket), this compact yet powerful 32W spotlight brings exceptional visibility to night operations, dramatically expanding the capabilities of your drone in low-light or complete darkness environments.

With an illuminance of 4.3 lux at 100m and 17 lux at 50m, the AL1 delivers a focused, high-intensity beam that ensures clear visibility over large areas. It offers two illumination modes: Always-on for sustained lighting and Strobe for signaling or attracting attention. The 23° illumination angle provides excellent throw distance while maintaining a wide enough coverage area — reaching up to 2,200 m² (Wide FOV) and 1,300 m² (Normal) at 100 meters.

The AL1 features a highly responsive gimbal with a mechanical tilt range of -140° to +50° and a controllable range of -90° to +35°. With a maximum tilt speed of 120°/s and gimbal accuracy of ±0.1°, operators can precisely direct the light exactly where it’s needed in real time. This level of control is critical for dynamic missions such as search and rescue, infrastructure inspection, law enforcement, and emergency response.

Built for professional use, the DJI AL1 Spotlight carries an IP55 protection rating, making it resistant to dust and water ideal for challenging outdoor conditions. It operates reliably in temperatures ranging from -20°C to 50°C. The quick-release mounting system with hand-tightened screws allows for fast and secure attachment to compatible Matrice 4D drones.

Key benefits include:
Enhanced Situational Awareness: Illuminate large areas from a safe distance during nighttime operations.
Mission Versatility: Supports public safety, firefighting, wildlife monitoring, security patrols, and industrial inspections.
Lightweight & Efficient: Minimal impact on flight time while delivering powerful lighting performance.
Seamless Integration: Fully compatible with DJI enterprise drone ecosystem and remote controllers for intuitive operation.
Whether you’re conducting critical night-time search operations, inspecting power lines after dark, or supporting law enforcement in urban environments, the DJI AL1 Spotlight significantly improves operational effectiveness and safety. Its combination of powerful output, precise control, rugged design, and lightweight construction makes it an essential tool for any professional drone program that operates in low-light conditions.

Elevate your night operations with the DJI AL1 Spotlight reliable illumination when and where you need it most.
